UJ OPTICS

NBP 470nm 50x50x1.0mm FWHM 10nm OD4@200-1100nm filter narrow band pass filter

DETAILS


NBP470nm narrow bandpass filter

Application fields of 470nm narrow-band filter: fluorescence analyzer, enzyme marker, three-dimensional scanner, wireless transmission equipment, mobile phone bar code scanning, infrared electronic whiteboard, infrared camera, infrared touch screen, iris recognition, infrared medical instruments, infrared ink recognition, face recognition sensor system, handheld infrared laser rangefinder, laser rangefinder, optical instruments, medical and health equipment and testing instruments, etc.

ItemParameters
Product nameNBP470nm narrow bandpass filter
Model numberNBP-470nm
DescriptionHigh Reflection Filters
ProcessIAD Hard Coating
Centralwavelength(CWL)470±5nm
FWHM10±2nm
TransmittanceT>90%@470±5nm
Cut off rate:OD4 200-1100nm
Raw materialB270 or Corning gorilla glass or other optical glass
Surface quality(S/D)60/40 or better
Dimension50x50x1.0

NBP470nm narrow bandpass filter.jpg
