PNB586 Multiband Calibration Optical Glass Filter
PNB586 Multiband Calibration Optical Glass Filter is a praseodymium-neodymium glass designed for wavelength calibration. It features stable and distinct absorption peaks within the 200-2000nm wavelength range, particularly around 586nm. This filter is widely used for wavelength calibration in spectrophotometers, laser technology, mineral analysis, and optical instrument testing. The PNB586 filter offers high transmittance and excellent chemical stability, maintaining performance across a wide temperature range for various applications. Custom processing is available to meet specific application requirements, including adjustments to size, shape, and surface treatment.
Product show
| Comparitive Type List Of Colored Filter Glass | ||
| CDGM | SCHOTT | HOYA |
| PNB586 | BG20 | V-10 |
| Parameter of PNB586 Multiband Calibration Optical Glass Filter | |
| Product name | PNB586 Multiband Calibration Optical Glass Filter |
| Place of origin | Jiangsu, China |
| Customized | OEM ODM |
| Model number | PNB586 |
| Substrate Material | Optical filter glass |
| Dimension | Customized |
| Dimension Tolerance | 0.0/-0.1mm |
| Thickness | 2mm 3mm or customized |
| Thickness tolerance | 0/-0.05mm |
| Chamfer | 0.25*45 degree or as needed |
| Tempered | Harden as requirement |
| Coating | Uncoated or Coated as requirement |
| Transmittance | T>90% |
| Surface quality S/D | 60/40 or better |
| Surface | λ/4 or higher |
| Application | Optical Area,optical instruments,stage light,gobo light |
| Sample | In stock filters mostly provide for free |
PNB586 Multiband Calibration Optical Glass Filter
Characteristics Technical Standard Quality Level of Multiband Calibration Selective Absorption Optical Glass Filter
