DETAILS
905nm Laser Lidar Filter
1,905nm wavelength laser technology development is faster at present there are many mature technology programs with the use of.
2,905nm filter emitted laser beam in the air propagation is more stable.
3,905nm laser is currently relative to the 1550nm filter to do the lens of the laser is relatively low cost 905nm.
Item | Parameters |
Product name | 905nm Laser Lidar Filter |
Model number | BP905 |
CWL | 905±5nm |
AOI | 0° |
FWHM | 8nm-30nm |
Transmittance | T>90% Customized |
Blocking Rate | >OD3-OD6 UV-NIR |
Blocking Band | 200nm-2000nm Customized |
Raw material | B270 D263T JGS1 or other optical glass |
Surface quality(S/D) | 60/40 or better |
Dimension | Customized |
Thickness | customized |
